Compoundvisier ULTIMA CPX III 400-9 von SHIBUYA
Technische Daten:
- Länge Auslegerschiene : 9"
- Gewinde : 10/32"
Inkl. Tasche und Zubehör
- Both sides of Ultima CPXIII’s elevation bar feature recessed metal sight scale plates. Each ULTIMA CPXIII includes a blank plate and reference scale. 8 double-sided sight scale plates, for a total of 16 scale options, are available sold separately. Printed sight tapes can be used on the blank plate supplied.
- Ultima CPXIII sights feature a revolutionary system eliminating backlash and play in the elevation adjustments: the ZPE system. A re-adjustable aluminum wedge, secured with Nord-Lock® washers, eliminates any gap between the threaded locking block and aperture block.
- The new flat-shelf indicator pin on Ultima CPXIII sights is easy to adjust, closer to the sight tape surface than ever before, while still offering enough clearance for layered tapes. Both side pins are locked by a cap screw from the side, preventing accidental movements when locking them down!
- Shibuya’s innovative Tria-Lock system keeps the scope rod approx. 1/2″ closer to the elevation bar than conventional target sights. This significantly reduces moment effected on the windage unit – a significant factor in development of play and faults!
- The innovative new Tria-Lock system encloses the scope rod holder from three sides, keeping it perfectly aligned and without play to produce a rattle-free, zero-tolerance environment.
- X-Lock System: re-adjustable, zero-tolerance fit between the windage unit and sight frame. Super-slick and durable polyacetal resin guide spacers enclose the elevation rail, re-adjustable at the turn of a set screw. - All parts field-adjustable and -replaceable!
